Ferrite
Ferrite Magnet Material
*Download:
Catalogue
of Ferrite Magnets
 (3.38MB)
|
Chinese standard |
|
Type |
Standard
same
with
TDK |
Br(mT) |
HcB(kA/m) |
Hcj(kA/m) |
(BH)max(KJ/m3) |
|
Y10T |
|
200-235 |
125-160 |
210-280 |
6.5-9.5 |
|
Y20 |
|
320-380 |
135-190 |
140-195 |
18.0-22.0 |
|
Y22H |
|
310-360 |
220-250 |
280-320 |
20.0-24.0 |
|
Y23 |
|
320-370 |
170-190 |
190-230 |
20.0-25.5 |
|
Y25 |
|
360-400 |
135-170 |
140-200 |
22.5-28.0 |
|
Y28H-3 |
FB5E
|
370±15 |
293±15 |
395±15 |
27±2 |
|
Y29H-1 |
FB6E |
380±10 |
290±15 |
395±15 |
27±1.6 |
|
Y30H-1 |
FB3N |
390±10 |
245±15 |
255±20 |
29.5±2.5 |
|
Y30H-2 |
FB5H |
405±10 |
290±15 |
325±15 |
30.5±2 |
|
Y30H-3 |
FB4B |
400±10 |
245±15 |
258±15 |
30±2.0 |
|
Y30H-4 |
FB6H |
400±10 |
305±15 |
360±15 |
30±1.6 |
|
Y30H-5 |
|
400±10 |
300±15 |
400±15 |
30±1.6 |
|
Y32 |
FB4A |
410±10 |
175±15 |
180±15 |
32±1.8 |
|
Y33 |
FB4X |
420±10 |
235±15 |
240±15 |
33±1.8 |
|
Y33H |
FB5B |
420±10 |
265±15 |
270±15 |
33±2.0 |
|
Y33H-2 |
FB6B |
420±10 |
300±15 |
320±15 |
33.4±1.6 |
|
Y34H-1 |
|
430±10 |
245±15 |
255±15 |
34±1.6 |
|
Y34H-2 |
|
430±10 |
260±15 |
280±15 |
34±1.6 |
|
Y34H-3 |
|
430±10 |
285±15 |
290±15 |
34±1.6 |
|
Y35 |
FB5N |
440±10 |
230±15 |
235±15 |
35±1.6 |
|
Y36 |
FB6N |
440±10 |
259±12 |
362±12 |
36.7±1.6 |
|
Y38 |
|
450±10 |
295±10 |
300±10 |
38.6±2 |
|
Y40 |
FB9B |
450±10 |
340±15 |
350±10 |
39.8±2.1 |
|
|
Material
|
Br
|
Hcb
|
Hcj
|
(BH)max
|
|
mT
|
KG
|
KA/m
|
KOe
|
KA/m
|
KOe
|
KJ/m3
|
MGOe
|
|
C1
|
230
|
2.3
|
148
|
1.86
|
258
|
3.5
|
8.36
|
1.05
|
|
C5
|
380
|
3.8
|
191
|
2.4
|
199
|
2.5
|
27
|
3.4
|
|
C7
|
340
|
3.4
|
258
|
3.23
|
318
|
4.00
|
21.9
|
2.75
|
|
C8(C8A)
|
385
|
3.85
|
235
|
2.95
|
242
|
3.05
|
27.8
|
3.5
|
|
C9
|
380
|
3.8
|
280
|
3.516
|
320
|
4.01
|
26.4
|
3.32
|
|
C10
|
400
|
4.0
|
288
|
3.617
|
280
|
3.51
|
30.4
|
3.82
|
|
C11
|
430
|
4.3
|
200
|
2.512
|
204
|
2.56
|
34.4
|
4.32
|
|
|
|
|
Europe
standard
The
standard
from
International
Electronics
Committee
(IEC404-8-1)
O×100=Y10T=C1
O×300=Y30=C5
O×330=Y30BH
|
|
Grade
|
Allowed
Value
(min/typical)
|
|
Br
|
Hcb
|
Hcj
|
(BH)max
|
|
mT
|
KG
|
KA/m
|
KOe
|
KA/m
|
KOe
|
KJ/m3
|
MGOe
|
|
HF8/22
|
200/220
|
2.00/2.20
|
125/140
|
1.57/1.76
|
220/230
|
2.76/2.89
|
6.5/6.8
|
0.8/1.1
|
|
HF20/19
|
320/333
|
3.20/3.33
|
170/190
|
2.14/2.39
|
190/200
|
2.39/2.51
|
20.0/21.0
|
2.5/2.7
|
|
HF20/28
|
310/325
|
3.10/3.25
|
220/230
|
2.76/2.89
|
280/290
|
3.52/3.64
|
20.0/21.0
|
2.5/2.7
|
|
HF22/30
|
350/365
|
3.5/3.65
|
255/265
|
3.20/3.33
|
290/300
|
3.64/3.77
|
22.0/23.5
|
2.8/3.0
|
|
HF24/16
|
350/365
|
3.5/3.65
|
155/175
|
1.95/2.20
|
160/180
|
2.01/2.26
|
24.0/25.5
|
3.0/3.2
|
|
HF24/23
|
360/370
|
3.5/3.65
|
220/230
|
2.76/2.89
|
230/240
|
2.89/3.01
|
24.0/25.5
|
3.0/3.2
|
|
HF24/35
|
370/380
|
3.60/3.70
|
260/270
|
3.27/3.39
|
350/360
|
4.40/4.52
|
24.0/25.5
|
3.0/3.2
|
|
HF26/16
|
370/380
|
3.70/3.80
|
155/175
|
1.95/2.20
|
160/180
|
2.01/2.26
|
26.0/27.0
|
3.2/3.4
|
|
HF26/18
|
370/380
|
3.70/3.80
|
175/190
|
2.20/2.39
|
180/190
|
2.26/2.39
|
26.0/27.0
|
3.3/3.4
|
|
HF26/24
|
370/380
|
3.70/3.80
|
230/240
|
2.89/3.01
|
240/250
|
3.01/3.14
|
26.0/27.0
|
3.3/3.4
|
|
HF26/26
|
370/380
|
3.70/3.80
|
230/240
|
2.89/3.01
|
260/270
|
3.27/3.39
|
26.0/27.0
|
3.3/3.4
|
|
HF26/30
|
385/395
|
3.85/3.95
|
260/270
|
|
|
|
|
|
|
|
